Dettagli:
|
| Corrente di scarica massima: | 100A | Dimensioni della batteria: | 442*500*140 mm |
|---|---|---|---|
| Capacità Nominale: | 100 Ah | Voltaggio nominale: | 51,2 V |
| Energia nominale: | 5120w | Corrente di carica massima: | 100A |
| Tipo di cella: | cellula lifepo4 | Tensione di taglio di ricarica: | 56,2 V |
| Corrente di ricarica standard: | 50A | Scarico della tensione d'interdizione: | 45.6V |
| Corrente di scarica massima: | 200A | Comunicazione: | CAN/RS485/RS232/Bluetooth (opzionale) |
| Evidenziare: | 48V lithium battery with Bluetooth,wall mount lithium battery with app,home battery storage with SOC monitor |
||
✅ Far longer cycle life vs lead acid & generic lithium batteries
✅ Slim wall design saves 60% installation space compared to floor-standing battery cabinets
✅ Traceable top-tier brand cells with full capacity guarantee
✅ All-in-one safety BMS prevents all common battery failure hazards
✅ Factory direct pricing, 10 years lithium battery manufacturing experience
✅ Customization support for housing, communication and capacity
✅ Bulk order fast lead time for solar installers & wholesale distributors
✅ Compatible with most mainstream 48V solar hybrid inverters worldwide
| Product Model | KM48V100P2 |
|---|---|
| Nominal Voltage | 51.2V |
| Nominal Capacity | 100Ah |
| Nominal Energy | 5120Wh |
| Cell Type | LiFePO4 Cell |
| Charging Cut-off Voltage | 56.2V |
| Max Charging Current | 100A |
| Standard Charging Current | 50A |
| Discharging Cut-off Voltage | 45.6V |
| Discharging Current | 50A |
| Max Continuous Discharging Current | 100A |
| Peak Discharging Current (3S) | 200A |
| BMS Protection | Overcharging/over-discharging, Over-voltage/Over-current, Short Circuit, etc. |
| Battery Size | 442×500×140mm |
| Communication | CAN/RS485/RS232/Bluetooth (optional) |
| Certificate | UN38.3/MSDS/Sea/Air Transport Report/CE/IEC |
